QY160K Truck Crane

QY160K is the truck crane with the largest tonnage in the world. The boom length and lifting capacity is a great breakthrough in the 6-axle truck crane. The full extension length of the boom is 62m, and can be equipped with 28m vice boom. The maximum counterweight is 50t. The outrigger span is 7.8×8.0m, which can realize 360°full turn with the same lifting capacity, featuring large working scope and strong lifting capacity. The maximum travel speed is 80km/h, and the maximum grade ability is 40%, having excellent travel performance.

Parameter

Dimension	Unit	QY160K
Overall length	mm
Overall width	mm
Overall height	mm
Weight
Total weight in travel	kg	54900
Front axle load	kg
Rear axle load	kg
Power
Engine model		OM460LA.E3A/1
Engine rated power	kW/(r/min)	360/1800
Engine rated torque	N.m/(r/min)
Travel
Max. travel speed	km/h	80
Min. turning diameter	m	26
Min. ground clearance	mm	300
Approach angle	°	20
Departure angle	°	14
Max. grade ability	%	40
Fuel consumption for 100km	L	75
Main performance
Max. rated total lifting capacity	t	160
Min. rated working radius	mm
Turning radius at turntable tail	m
Max. lifting torque	kN.m	5253
Base boom	m
Fully extended boom	m	61.4
Fully extended boom+ jib	m	88.6
Longitudinal outrigger span	m	7.8
Lateral outrigger span	m	8
Working speed
Boom luffing time	s
Boom full extension time	s
Max. swing speed	r/min	1.8
Max. speed of main winch (single rope) (no load)	m/min	110
Max. speed of aux. winch (single rope) (no load)	m/min

The specification is subject to change without notice.
