6X4 NXG3251D3AKC NXG3251D3KC NXG3250D3BKC NXG3250D3KCL NXG3251D3BKC
Parameter
|
Model |
NXG3251D3AKC |
NXG3251D3KC |
NXG3250D3BKC |
NXG3250D3KCL |
NXG3251D3BKC |
||
|
Driving Mode |
6×4 |
||||||
|
Performance Parameter |
|||||||
|
Max. Travel Speed (km/h) |
80 |
80 |
80 |
80 |
80 |
||
|
Max. Gradeability (%) |
20 |
20 |
20 |
20 |
20 |
||
|
最大驻坡度(%) |
20 |
20 |
20 |
20 |
20 |
||
|
Min. Turning Radius (m) |
23 |
23 |
23 |
23 |
23 |
||
|
Fuel Tank capacity(L) |
240 |
240 |
240 |
240 |
240 |
||
|
Min. Ground Clearance [Full-load](mm) |
245 |
245 |
245 |
245 |
245 |
||
|
Electronic system (v) |
24 |
24 |
24 |
24 |
24 |
||
|
Mass |
|||||||
|
Weight (kg) |
12400 |
12400 |
12400 |
12400 |
12400 |
||
|
Rated load (kg) |
12400 |
12400 |
12400 |
12400 |
12400 |
||
|
Max. Weight (kg) |
24995 |
24995 |
24995 |
24995 |
24995 |
||
|
Dimension |
|||||||
|
Overall length (mm) |
8115,8270 |
8115,8270 |
8115,8270 |
8570,8670 |
8115,8270 |
||
|
Overall width (mm) |
2495 |
2495 |
2495 |
2495 |
2495 |
||
|
Overall height [empty-load](mm) |
3380 |
3380 |
3380 |
3380 |
3380 |
||
|
Wheel base (mm) |
3650+1350 |
3650+1350 |
3650+1350 |
4000+1350 |
3650+1350 |
||
|
车架(mm) |
320 |
320 |
320 |
320 |
320 |
||
|
Spring |
9/13 |
9/13 |
9/13 |
9/13 |
9/13 |
||
|
Main parts |
|||||||
|
Driving room |
平/中顶 |
平/中顶 |
平/中顶 |
平/中顶 |
平/中顶 |
||
|
Engine |
WP10.336N WP10.300N WP10.270N |
WP10.336N WP10.300N WD615.96C
|
ISLe340 30 |
WP10.336N WD615.95C |
WD615.92C YC6M290-32 |
||
|
Transmission box |
RT-11509c |
9JS135 12JSD180TA
|
RT-11509c |
RT-11509c |
9JS135 |
||
|
Front axle |
7.5吨 |
7.5吨 |
7.5吨 |
7.5吨 |
7.5吨 |
||
