SQ25ZK6Q Truck-Mounted Crane
Pamameter
|
Max Lifting Moment |
62.5 |
t.m |
|
Max Lifting Capacity |
25000 |
kg |
|
Recommend Power Needed At Recommend Oil Flow |
50 |
kw |
|
Max Oil Flow of Hydraulic System |
80 |
L/min |
|
Rated Pressure Of Hydraulic System |
31.5 |
MPa |
|
Oil Tank Capacity |
300 |
L |
|
Rotation Angle |
(360°)All Rotation |
。 |
|
Crane Weight |
7945 |
kg |
|
Installation Space |
3000 |
mm |
|
Choice of Chassis |
专用汽车底盘（无国家公告） |
|
| Working radius(m) | 2.5 | 4.22 | 5.93 | 7.74 | 9.59 | 11.48 | 13.43 | 15.45 |
| Lifting capacity(kg) | 25000 | 14000 | 9000 | 6500 | 5000 | 4000 | 3000 | 2500 |
|
Working radius(m) |
18.63 |
20.31 |
22.02 |
23.76 |
25.53 |
|
Lifting capacity(kg) |
1050 |
950 |
800 |
700 |
600 |
