SQ5SK2Q/K3Q Truck-Mounted Crane

SQ5SK2Q/K3Q Truck-Mounted Crane



Parameter



Model

SQ5SK2Q/SQ5SK3Q

Unit

Max Lifting Capacity

5000

kg

Max Lifting Moment

12.5

T.M

Recommend Powe

18

kw

Max Oil Flow of Hydraulic System

32

L/min

Max Pressure of Hydraulic System

18

MPa

Oil Tank Capacit

90

L

Rotation Angle

All Rotation

Crane Weight

2074/2170

kg

Installation Space

900

mm

Choice of Chassis

CA1140PK2L3EA80青岛;DFL1140B东风;EQ1126KJ1东风;HFC1132KR1K3江淮;LZ1120LAPT东风柳汽;EQ1141NBJ2东风;EQ5201GFJ6东风;EQ5201GFJ6东风;NXG1160D3ZAL1X徐工

SQ2SK1Q Lifting capability diagram

Working radius(m)

2.5

3.62

6.05

8.5

Lifting capacity(kg)

5000

2800

1500

1100

SQ2SK2Q Lifting capability diagram

Working radius(m)

2.5

3.62

6.05

8.5

11

Lifting capacity(kg)

5000

2800

1500

1100

400
