SQ3.2SK1Q/K2Q Truck-Mounted Crane
Parameter
|
Model |
SQ3.2SK1Q/SQ3.2SK2Q |
Unit |
|
Max Lifting Capacity |
3200 |
kg |
|
Max Lifting Moment |
6.72 |
T.M |
|
Recommend Power |
14 |
kw |
|
Max Oil Flow of Hydraulic System |
25 |
L/min |
|
Max Pressure of Hydraulic System |
20 |
MPa |
|
Oil Tank Capacity |
30 |
L |
|
Rotation Angle |
All Rotation |
|
|
Crane Weight |
1172/1316 |
kg |
|
Installation Space |
850 |
mm |
|
Choice of Chassis |
EQ1092FJ1东风；EQ1092FJ东风；EQ1092F3GJ1；NKR77PLLWCJAY 庆铃；DFL1120B东风；EQ1081GJ12D5东风；HFC1083K103R1D江淮；EQ5121GFJ； |
|
|
SQ3.2SK1Q Lifting capability diagram |
||||||||
|
|
SQ3.2SK2Q Lifting capability diagram |
||||||||||
|
