XM200K Cold Milling Machine

XM200K Cold Milling Machine



XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.

The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.

Performance and characteristic

High strength milling rotor drive by belt ,reliable and high efficiency.

Four tracks driving system ,power traction ,four kids of steering modes ,flexible to travel.

Full automatic power adjusting system ,realizing the automatic power distribution between the milling power and driving power.

Advanced automatic control system of milling depth ,easy operation and reliable.

Original imported electrical control engine ,Euro emission standard ,reliable operation and high efficiency of fuel consumption.

All hydraulic components and transmission parts adopts intermational well-known brands ,advanced performance and reliable operation.

Intelligent control system can realize advanced function of online display faults diagnosis faults warningmaintainence ,under working mode and travel mode.


Model
XM200K
Max. milling with
mm
2000
Max. milling depth
mm
320
Milling wheel
Number of tools
168
Drum diameter with tools
mm
980
Engine
Model
QS×15Ⅲ
Rated power
kW
447
Rated speed
rpm
2100
Specifications
Operating speed
m/min
0~30
Travel speed
km/h
0~5
Ground clearance
%
80
Ground clearance
mm
≤320
Operating weight
kg
32500
Volume
Fuel tank
L
1300
Hydraulic oil tank
L
360
Water tank
L
3400
Conveyor
Width
mm
8000
Measurement
Overall machinery LxWxH
mm
7300×2500×3000
Conveyor LxWxH
mm
8000×1150×900
Travel mode
Track



All technical parameters are subject to change without prior notice because of technical improvements.
