Current Position: Products > Roadheader > XCMG
EBZ160 Roadheader

Cutting motor power

160/80Kw

Oil pump power

75Kw

Cutting hardness

70MPa

Cutting range

Height:4.8m

 Width:5.4m

Operating weight

48t

Dimension(LXWXH)

9.3X2.9X1.6 m

Max Non-removable size(LXWXH)

3.6X1.66X1.54 m

Max Non-removable weight

8348 Kg

Cutting head speed

48/24 r/min

Star wheel speed

33 r/min

Load capacity

4.2 m³/min

First transport aircraft speed

61 m/min

Working speed

06 m/min

Grade ability

±16º

Gantry height

400 mm

Underground water pressure

3-8 MPa

Fuel Tank capacity

500 L

Ground Pressure

0.14 MPa

Undercover depth

0.216m

Ground clearance

0.25m

Voltage

AC1140/660V
