QY40V532 Truck Crane

QY40V532 Truck Crane



Features



The QY40V532 truck crane, which is developed independently to adapt to the market demands, is a new-generation and high-performance product integrating our company many years’ manufacturing experience with advanced technologies. Its performances such as lifting height, boom length, working speed and lifting capacity have achieved advanced international level.

The truck crane, with spacious cab and luxurious equipments, adopts full slewing system, telescopic boom, hydraulic proportional control system and self-made full-width special purpose chassis with four axles. 8×4 drive and hydraulic power steering mechanism provides the crane with good driving performance and flexible steering.

The system with latest load feedback hydraulic operated proportional directional control valve and quadruple gear pump, and the safety devices fitted in hydraulic system, such as relief valve, balance valve, hydraulic lock and brake valve etc., prevents the oil line from overloading and the accidents caused by oil pipe breakage to makes full use of the working capacity of each actuating mechanism. Thus the reliability and safety of the crane are increased.

The safety devices such as load moment limiter, and the complete lighting system equipped in the crane ensure your safety during operation and are convenient for night work.

This crane has a novel style which makes it beautiful in figure, in form and in color



Parameter



Item

Value

Remarks

Working performance specification

Max. rated total lifting capacity kg

40000

Max. load moment of basic boomkN.m

1430

Max. load moment with max. main boom lengthkN.m

800

Max. lifting height of basic boomm

12.0

Max. lifting height of main boomm

41.7

Deformation of boom is not taken into consideration.

Max. lifting height of fly jibm

56.4

Working speed

Max. speed of single rope on main winchm/min

130

The 4th layer of drum

Max. speed of single rope onauxiliary winchm/min

80

The 2nd layer of drum

Derricking time of booms

40

Telescopic time of booms

80

Slewing speedr/min

0~2.2

Traveling specification

Max. traveling speedkm/h

70

Max. gradeability%

30

Min. turning circle diameterm

24

Min. ground clearancemm

280

Limits for exhaust pollutants and smoke

Comply with related standards

GB3847-2005 GB17691 -2005

(Stage III)

Oil consumption per hundred kilometers L

48

Mass specification

Deadweight of crane in traveling conditionkg

37000

Complete vehicle kerb masskg

36870

Front axle loadkg

13700

Rear axle loadkg

23300

Dimension specification

Overall dimensions (L×W×H)mm

13060×2750×3560

Base on outriggers m

5.60

Distance between outriggersm

6.90(fully)

Main boom lengthm

10.9~41.0

Main boom angle°

-2~80

Fly jib lengthm

9 ,15

Offset angle of fly jib°

0 , 30

Chassis

Model

ZLJ5414

Class

II

Engine

Model

WP10.290

QSL 325

Rated powerkW/r/min

213/2200

242/2100

Max. output torqueN.m/r/min

1160/1200~1600

1424/1500
